KX3Specifications Drilling capacity16 mm(0.6")

Table effective size550x160 mm(22"x6.3)

Table travel - X axis300 mm(12")

Table travel - Y axis120 mm(4.7")

Head travel - Z axis270 mm(11")

Motor of X axis4 NMotor of Y axis4 NMotor of Z axis6 NThroat232 mm(9")

Table T-slot size12 mm(0.5")No. of T-slots on table3Position accuracy0.01 mmSpindle taperMT3/R8/BT30

Speed of Spindle100 - 5000 RPMMax.

Spindle motor torque @ 1500RPM5.5 N.m

.Spindle motor power1000

WMachine size (LxWxH)870x690x1625

mmPacking size (LxWxH)1020x1000x1130

mmWeight (n.w./g.w.)210/260 KG
