技术参数

下料尺寸(圆钢/方钢)「Max.Cutting Diameter(Circular Steel/Square Steel)」￠160mm,a×amm,

方钢160×160mm

锯条规格(Hacksaw Blade)1×b×hmm 350×25×1.25mm

往复次数(To and Frequency)85/min

锯片行程(Blade Stock)100-190mm

电动机单机或三相(Electric Motor single hase Dr3-phase)0.37kw

冷却泵CBK1.2J齿轮泵(Coolant pump)CB-K1.2Jgear pump

外形尺寸「Overall Dimensions(L×W×H)」910×330×640mm

机床净重(Mschine Net Weight)160kg
