KB1气动驱动制动器
技术数据
制动力F：
KB1-1 556N 6bar
KB1-2 1516N 6bar
KB1-3 3888N 6bar
加速力矩
=F·[制动盘半径(m)-0.024]=Nm
zui大总磨损: 6 mm
新摩擦片厚度: 5 mm
持续滑动时的热容量Qc:1 kW
Technical data
Braking force F:
KB1-1 556 N at 6 bar
KB1-2 1516 N at 6 bar
KB1-3 3888 N at 6 bar
Dynamic torque
= F.(disc radius in m - 0.024) = Nm
Max total wear: 6 mm
Thickness of new lining: 5 mm
Continuous thermal capacity Qc: 1 kW
KB2气动驱动制动器
厚度为25.4mm的制动盘同样适用, 产品代号不同
Available also for disc thickness 25,4 mm.
技术数据
制动力F：
KB2-1 1730 N 6bar
KB2-2 4100 N 6bar
KB2-3 8000 N 6bar
KB2-4 13700N 6bar
动态力矩
=F·[制动盘半径(m)- 0.03) = Nm
zui大总磨损：16 mm
新摩擦片厚度：16 mm
持续滑动时的热容量
Qc: 1.7 kW
双倍制动垫型持续滑动时的热容量
Qc: 2.7 kW
Technical data
Braking force F:
KB2-1 1730 N at 6 bar
KB2-2 4100 N at 6 bar
KB2-3 8000 N at 6 bar
KB2-4 13700 N at 6 bar
Dynamic torque
= F.(disc radius in m - 0.03) = Nm
Max total wear: 16 mm
Thickness of new lining: 16 mm
Continuous thermal capacity
Qc: 1.7 kW
Continuous thermal capacity
for double pad version Qc: 2.7 kW
KB3气动驱动制动器
技术数据
制动力F：
KB3-1 670 N 6bar
KB3-2 1800 N 6bar
KB3-3 3550 N 6bar
加速力矩
=F·[制动盘半径(m)-0.032]=Nm
zui大总磨损: 14 mm
新摩擦片厚度: 16 mm
持续滑动时的热容量Qc: 1.7 kW
双倍制动垫型持续滑动时的热容量
Qc: 2.7 kW
Technical data
Braking force F:
KB3-1 670 N at 6 bar
KB3-2 1800 N at 6 bar
KB3-1 3550 N at 6 bar
Dynamic torque
= F.(disc radius in m - 0.032) = Nm
Max total wear: 14 mm
Thickness of new lining: 16 mm
Continuous thermal capacity
Qc: 1.7 kW
Continuous thermal capacity
for double pad version Qc: 2.7 kW
KB4气动驱动制动器
技术数据
制动力F：
KB4-1 1600 N 6bar
KB4-2 3800 N 6bar
KB4-3 7500 N 6bar
KB4-4 12700 N 6bar
动态力矩
=F·[制动盘半径(m)-0.033]=Nm
zui大总磨损：12 mm
新摩擦片厚度：11 mm
持续滑动时的热容量Qc: 3.4 kW
Technical data
Braking force F:
KB4-1 1600 N at 6 bar
KB4-2 3800 N at 6 bar
KB4-3 7500 N at 6 bar
KB4-4 12700 N at 6 bar
Dynamic torque
= F.(disc radius in m - 0.033) = Nm
Max total wear: 12 mm
Thickness of new lining: 11 mm
Continuous thermal capacity Qc: 3.4 kW
KB7气动驱动制动器
技术数据
制动力F：
KB7-1 20180 N 6bar
KB7-2 36600 N 6bar
动态力矩
=F·[制动盘半径(m)-0.065]=Nm
zui大总磨损: 12 mm
新摩擦片厚度: 13 mm
持续滑动时的热容量Qc: 20 kW
Technical data
Braking force F:
KB7-1 20180 N at 6 bar
KB7-2 36600 N at 6 bar
Dynamic torque
= F.(disc radius in m - 0.065) = Nm
Max total wear: 12 mm
Thickness of new lining: 13 mm
Continuous thermal capacity Qc: 20 kW
KB8气动驱动制动器
技术数据
制动力F：
KB8-1 20180 N 6bar
KB8-2 36600 N 6bar
动态力矩
=F·[制动盘半径(m)-0.065]=Nm
zui大总磨损: 12 mm
新摩擦片厚度: 13 mm
持续滑动时的热容量Qc: 20 kW
Technical data
Braking force F:
KB8-1 20180 N at 6 bar
KB8-2 36600 N at 6 bar
Dynamic torque
= F.(disc radius in m - 0.065) = Nm
Max total wear: 12 mm
Thickness of new lining: 13 mm
Continuous thermal capacity Qc: 20 kW
KB5气动驱动制动器
厚度为25.4-30-40mm的制动盘同样适用。
Available also for disc thickness 25.4-30-40mm.
技术数据
制动力F:
KB5-1 6bar时制动力为1600N
KB5-2 6bar时制动力为3800N
KB5-3 6bar时制动力为7500N
KB5-4 6bar时制动力为12700N
加速力矩
=F [制动盘半径（m）-0.033]=Nm
一对摩擦片zui大总磨损：12mm
新单片摩擦片厚度：11mm
持续散热功率
Qc：3.4KW
Technical data
Braking force F:
KB5-1 1600 N at 6 bar
KB5-2 3800 N at 6 bar
KB5-3 7500 N at 6 bar
KB5-4 12700 N at 6 bar
Dynamic torque
= F.(disc radius in m-0.033)=Nm
Max total wear: 12 mm
Thickness of new lining: 11 mm
Continuous thermal capacity
Qc: 3.4kW
KB6气动驱动制动器
技术数据
制动力F:
KB6-1 6bar时制动力为3610N
KB6-2 6bar时制动力为7200N
KB6-3 6bar时制动力为12500N
KB6-4 6bar时制动力为19000N
加速力矩
=F.[制动盘半径（m）-0.062]=Nm
一对摩擦片zui大总磨损：10mm
新单片摩擦片厚度：8mm
持续散热功率
Qc：14KW
Technical data
Braking force F:
KB6-1 3610 N at 6 bar
KB6-2 7200 N at 6 bar
KB6-3 12500 N at 6 bar
KB6-4 19000 N at 6 bar
Dynamic torque
= F.(disc radius in m-0.062)=Nm
Max total wear: 10 mm
Thickness of new lining: 8 mm
Continuous thermal capacity
Qc: 14kW
