立式网带机
●用途：
用于不倒绒、摇粒绒、海绵、布类、EVA、人革、人造棉（喷胶棉）等上胶贴合。制鞋、制帽、手套、皮衣、汽车垫、玩具等原料上胶巾贴合。
●特点：
采用胶水作粘合剂和耐高温网带压著使之复合,使材料柔软,耐水洗,牢度高。可选用手轮调节/气动调节。
TYPE Vertical net belt compound machine
●Usage:
used for sponge, cloth, EVA, leather, rubber joint, etc. On regarding Clothing, shoe, hat, gloves, leather, car mat, toy materials such as towel on joint.
●Feature:
Using glue as binder and high-temperature net belt of the composite material, soft, resistance to water, high fastness. Can choose the handwheel adjustment/pneumatic adjustment.
技术参数Technical data:
1 | 型号Model | LH-2000型立式网带复合机 LH-2000TYPE Vertical net belt compound machine |
2 | 电源Power Supply | 380V 50HZ三相 （220V 单相）可根据要求订制 |
3 | 材料有效幅宽.Effective Breadth | 可根据客户所需订制1750mm According to customer requirements |
4 | 加热方式Heating method | 电加热或蒸气加热 Electric heating or Steam heating |
5 | 电加热辊筒直径Diameter of Drying Cylinder | Ø1500mm（Ø 1200mm、Ø 1800mm） |
6 | 电加热管规格Electric Heating Pipe Specifications | 27pcs*1.5kw=40.5kw |
7 | 蒸气压力Vapor pressure | 0.5mpa |
8 | 辊筒幅宽Width of Drying Cylinder | 可根据客户所需订制1850mm According to customer requirements |
9 | 上胶方式Gumming Way | 滚涂上胶Roll on glue |
10 | 传动功率Transmission Power | 3.7kw |
11 |
装机容量Installed Capacity | 大约About 45KVA |
12 |
设计贴合速度Design Production Rate |
1-45m/min |
13 |
外形尺寸Dimension(L*W*H) |
大约About 7300*2400*2600mm |
14 | 整机重量N.W | 大约About 4500KG |
